Pressure washers by Powerhorse deliver superior performance for cleaning driveways, sidewalks, vehicles, patios, and much more. Despite their utility, a pressure washer is prone to undergo starting problems, be it gas-powered or electric. The root cause of these issues lies in the engine/motor of your device.
Titan Powerhorse Pressure Washer Problems: Engine/Motor Troubleshooting & Repair
If a Powerhorse gas-pressure washer has difficulty starting, check that the carburetor jets and the air and fuel filters are clear of debris. Check for a vapor lock in the fuel lines and ensure that the fuel tank vents are clear. If a Powerhorse electric pressure washer does not start, check the input voltage, power supply, and fuses first. If the motor buzzes, look for a bad capacitor, a malfunctioning pump, or a buildup of pressure in the system.
This article focuses on the engine and motor-related issues of your Titan Powerhorse pressure washer. If you want to learn the complete troubleshooting and repair procedure, I suggest you read the whole article.
Contents
- 1 Problems with the Titan Powerhorse Gas Pressure Washer Engine
- 1.1 ● 1. Titan Powerhorse Pressure Washer: Keeps Stopping and Starting
- 1.2 ● 2. Titan Powerhorse Pressure Washer: The Engine won’t run
- 1.3 ● 3. Titan Powerhorse Pressure Washer: Engine Stops
- 1.4 ● 4. Titan Powerhorse Pressure Washer: Engine not providing enough Power
- 1.5 ● 5. Titan Powerhorse Pressure Washer: Oil Leak
- 1.6 ● 6. Titan Powerhorse Pressure Washer: Water in Oil
- 2 Titan Powerhorse Electric Pressure Washer Problems
- 3 Titan Powerhorse Pressure Washer troubleshooting table:
Problems with the Titan Powerhorse Gas Pressure Washer Engine
There are currently a few gas-powered pressure washers by Titan Powerhorse. Like the Powerhorse 3200 PSI, 2.6 GPM, and Powerhorse 4000 PSI, 4.0 GPM pressure washers.
A four-stroke petrol engine drives the pump of a Titan Powerhorse gas pressure washer. The addition of engine and fuel system components increases the system’s complexity and maintenance requirements. Due to this, gas-powered pressure washers encounter specific problems that need troubleshooting more frequently.
Common faults with Titan Powerhorse pressure washer engines include the following:
● 1. Titan Powerhorse Pressure Washer: Keeps Stopping and Starting
If your pressure washer repeatedly starts and stops, a clogged carburetor jet or a vapor lock in the fuel lines might be to blame. Sometimes, a fuel filter clogged with debris might create an issue.
Most engine starting problems with pressure washers are caused by carburetor or filter issues, as stale fuel deposits may block carburetor jets. Hence, the amount of fuel that enters the engine hampers combustion, reducing the engine’s power.
In addition to a clogged carburetor or filter, a vapor lock could be another cause of the issue. Generally, a vapor lock is created by an impediment in the fuel tank vents, which leads to a continuous accumulation of gas vapors in the fuel lines and eventually disrupts the engine’s fuel delivery.
– How to Fix?
To resolve this issue, thoroughly clean your carburetor’s jets with WD-40 or a carburetor-cleaning solution. Ensure that all flow channels have been thoroughly cleaned, including the bowl’s nut, which is also a jet. In addition to cleaning the carburetor, you should examine the fuel filter and replace it if necessary. I also recommend cleaning the fuel tank vents to prevent vapor buildup and vapor lock.
● 2. Titan Powerhorse Pressure Washer: The Engine won’t run
If your engine would not start, ensure that the spark plug is functioning correctly. If the problems persist, detach the carburetor and use carburetor-cleaning solutions to clean the ports.
Carbon accumulation erodes spark plug electrodes over time, lowering spark quality and making it more challenging to start the engine.
– How to Fix?
To examine the electrodes, you must remove the spark plug. Replace the plug if the electrodes have been compromised. Consider cleaning the carburetor on your pressure washer if the problem persists. Remove the carburetor and thoroughly clean it to remove any fuel residue. I recommend purchasing a carburetor repair kit with a cleaning solution to remove sticky deposits.
I recommend purchasing a carburetor repair kit with a cleaning solution to remove sticky deposits.
● 3. Titan Powerhorse Pressure Washer: Engine Stops
If your engine fails to start after a brief period of operation, inspect and clean the air and fuel filters thoroughly. Check for vapor lock in the tank and ensure that the carburetor is clean and well-adjusted.
Air and fuel filters prevent unwanted debris from entering the carburetor. As a result, dirt often builds in these filters, altering the air-fuel ratio and reducing the engine’s power.
Examine these filters to resolve the problem, and clean or replace them as necessary. Check the fuel tank vents for a vapor lock and adjust the carburetor screws if the problem persists.
● 4. Titan Powerhorse Pressure Washer: Engine not providing enough Power
Ensure the water supply is sufficient and the hoses are not kinked if the engine on your pressure washer is not providing enough power. It is essential to have a clean air filter and jets in the carburetor.
The air-fuel mixture may be too rich if the engine isn’t generating enough power. This means the engine gets excessive fuel but insufficient air to produce appropriate power after combustion. It might be the carburetor, the filters, or both.
– How to Fix?
To guarantee enough airflow, inspect the air filter, which should not be blocked with dust. In addition, the L and H screws of the carburetor must be correctly adjusted since they impact the engine’s low and high RPMs.
Also, check that no air is trapped in the pump and that the hoses are not twisted since this might cause the engine to undergo substantial back pressure. As a result, the power output may be decreased.
● 5. Titan Powerhorse Pressure Washer: Oil Leak
A worn-out seal is the most common cause of oil leaks in your engine. Most often, changing the seal would resolve the problem. In some instances, an overfilled oil tank might cause an oil leak.
You might get an oil seal kit to assist you in replacing various types of seals. Typically, all oil inlets on your engine are equipped with oil seals positioned on either side of the engine and capped.
– How to Fix?
Remove the seal with a screwdriver and inspect its condition. Replace it if it shows symptoms of wear. As a precaution, you should avoid overfilling your oil tank, as this might result in oil spilling from these inlets.
● 6. Titan Powerhorse Pressure Washer: Water in Oil
The presence of water in the engine oil indicates a faulty oil seal. In this instance, you should replace the seal according to the manufacturer’s guidelines.
When water is added to the oil, it turns milky. One possible cause is a worn oil seal; another less probable cause is a piston undergoing significant fatigue. Over time, mechanical wear causes the pistons’ metal to chip off, increasing the distance between the piston and the cylinder walls.
Consequently, water from the intake manifold that reaches the cylinder head may enter the crankcase and combine with the oil to form a milky suspension.
– Possible Solutions:
The seals and gaskets of your engine might be damaged. Hence, it would be best if you replaced the engine’s seal/head gasket. If the warranty on your engine is still valid, contact the manufacturer and request these replacements. I would not advocate changing the seals/gaskets by yourself and losing your warranty.
If the warranty on your engine has expired, you may get the seals repaired by a professional. In the case of a worn-out piston, contact the manufacturer to see if the engine is still covered by warranty. If this is not the case, the engine of your pressure washer will cease to operate, and you may need to acquire a new one.
Titan Powerhorse Electric Pressure Washer Problems
Titan Powerhorse produces a few electric models with pressure ratings of 2000 PSI and 2300 PSI and a flow rate of 1.2 GPM.
Electric pressure washers need less maintenance than their gas-powered counterparts. Using an electric motor simplifies a pressure washer compared to a gas version. As a result, the probability of failure, noise, and emissions are considerably reduced. Because of this, these pressure washers have become more popular with customers.
The next portion of the blog post discusses issues unique to Titan Powerhorse electric pressure washers. The most typical problem with electric pressure washer motors is that they do not start or stop abruptly. Occasionally, they may emit a buzzing sound without producing any power.
● Titan Powerhorse Electric Pressure Washer not running
Check the fuse and ensure the electrical outlet is functional if an electric pressure washer does not start. If the machine still does not start, the electric motor may be defective.
If the motor of your pressure washer is not functioning, examine the following:
– Step 1: Check the power outlet for problems
Check the electrical outlet first if your electric pressure washer isn’t functioning. Unplug the washer’s cord and examine the outlet with a voltage tester or similar instrument. If it continues to malfunction, use the pressure washer’s reset button. If the problem persists, examine the fuel box’s circuit breaker.
– Step 2: Examine the Fault Circuit Interrupter
Due to a voltage drop, a ground fault circuit interrupter (GFCI) may have been engaged. Reset the GFCI after unplugging the pressure washer. If your pressure washer is damp and activates when reconnected, allow it to dry before reattaching. If, after drying, the pressure washer does not start, go to the next step.
– Step 3: Inspect the Extension Cord
Remove the extension cord from your pressure washer and instantly connect it directly to a power outlet. Ensure that the plug is correctly inserted into the electrical outlet. If it works now, the extension cord most likely caused the issue.
– Step 4: Inspect the Fuse
If the power outlet is operational (with a bulb or other item plugged in), ensure that the machine’s fuse or the socket’s fuse is not blown. If you cannot locate the fuse, consult the handbook. The blown fuse must be replaced for the motor to function.
– Step 5: Examine the power cord
If it still doesn’t start, your pressure washer’s power cable may be faulty. By changing the power cord, this problem may be rectified. Confirm that the warranty on your pressure washer is still valid. Alternatively, you may replace the cable yourself or contact a professional.
– Step 6: Examine the Capacitor
A pressure washer with a faulty capacitor often generates a buzzing noise from the motor. You can change the capacitor on your own if this is the problem. If this task is not for you, you should seek professional assistance.
If the pressure washer motor does not start after attempting all the above steps, we may deduce that the motor has failed and must be repaired/replaced by the manufacturer.
● Titan Powerhorse Electric Pressure Washer Motor Stops
The most likely causes of pressure washer motor halt are a socket power failure or a faulty capacitor. Sometimes, a voltage drop in the main socket might cause the device to shut off.
The motor turns off when the voltage falls below a specified threshold. To determine this, use a multimeter to measure the socket’s voltage. Depending on where you live, pressure washers have different voltage requirements. Pressure washers are often powered by voltages around 140V and 240V.
If the voltage is correct yet the washer would not start, replacing the motor’s capacitor may be necessary. It is characterized by the motor humming and generating much less power. After replacing the capacitor, the pressure washer should be rechecked. Hopefully, it will resume now that the previous action has been taken. If your pressure washer doesn’t start, contact the manufacturer to have the faulty electric motor repaired or replaced.
● Titan Powerhorse Electric Pressure Washer Motor Makes a Buzzing Noise
A buzzing sound coming from the motor of your electric pressure washer is suggestive of a malfunctioning capacitor or a significant pressure buildup in the system. There might also be a problem with the pump.
- Capacitor: A faulty capacitor is the most common source of a buzzing sound in a motor. Insufficient charge storage results in a drop in motor RPMs. Replace the capacitor and see if the buzzing stops.
- Low Voltage: If the input voltage is below the functioning range of the pressure washer, the motor may not run at the appropriate RPMs and emit a buzzing sound instead.
- Pressure Buildup: When the spray gun is inactive, water pressure builds up in the hoses. This causes substantial back pressure on the pump and motor, which reduces the rotational speed. To reduce the load on the engine, release the water by pressing the spray gun.
- Damaged pump: If pressure washer pumps are not properly maintained, they are prone to fail and cause the engine to overheat due to inadequate pump pressure. Ensure your pump is timely oiled to keep it in a workable condition.
Titan Powerhorse Pressure Washer troubleshooting table:
Problem | Cause | Solution |
The pressure washer is not producing high pressure | Hose with small diameter | Replace your hose with a 1″ (25mm) or 5/8″ (16mm) hose |
Restricted water supply to the washer | Check for the kinks and leaks in the hose | |
Inadequate water supply | Ensure the water source is unobstructed and fully turned on | |
Clogged intake filter | Remove the filter and rinse it with warm water | |
Air in the pump | Ensure that the hose and fittings are airtight. Shut off the washer and squeeze the trigger until water flows steadily from the spray tip | |
The suction tube or detergent bottle is not connected properly | Install the suction tube and detergent bottle correctly | |
Detergent too thick | Dilute the thick detergent by adding water | |
Obstructed spray tip | Remove the debris with a needle | |
No pressure tip on the wand | Install a suitable pressure tip at the end of the wand | |
If your model has a belt, it can be loose. | Tighten or replace the belt. |
Problem | Cause | Solution |
Pulsing pressure washer (output pressure varies high and low) | Inadequate water supply | Ensure that the water source is fully on and check the hose for kinks and blockage |
Obstructed spray tip | Remove the debris with a needle | |
Pump sucking air | Ensure that the hose and fittings are airtight. Shut off the washer and squeeze the trigger until water flows steadily from the spray tip | |
Clogged intake filter | Remove the filter and rinse it with warm water | |
Calcified hose, tip, or trigger | Clean the hose, pressure tip, or trigger with vinegar or a cleaner designed for this purpose |
Problem | Cause | Solution |
Noisy Pump | Air in the pump | Ensure that the hose and fittings are airtight. Shut off the washer and squeeze the trigger until water flows steadily from the spray tip |
Clogged inlet filter | Remove the filter and rinse it with warm water | |
Pump leaking water | Damaged or worn water seals | Replace the seals with new ones or call a professional |
Loose fittings | Ensure that all the fittings are tight | |
Erratic water pressure, changing up and down | Unloader valve | Check and clean the unloader valve. If in bad shape, replace it |
No output pressure. Or the motor stops when using the trigger (electric models) | Unloader valve | Check and clean the unloader valve. If in bad shape, replace it |
● Titan Powerhorse Gas Pressure Washer Engine troubleshooting table:
Problem | Cause | Solution |
Leaks in the spray wand, spray tip, or extension | Damaged or broken O-rings or plastic insert | Replace the worn O-rings or call a professional |
Pressure washer pump dripping oil | Worn or damaged oil seals | Inspect the oil seals and replace them if worn |
No water from the washer outlet | The water supply is off | Turn the water supply ON |
Kink in the hose or faucet not fully open | Remove any kinks and debris from the hose or water lines. Check and fully open the faucet. |
Problem | Cause | Solution |
The motor won’t start | Check the battery | Check if the battery is charged correctly. Charge or replace when in bad condition. Examine the battery terminals for a proper connection. Clean if needed. |
Check the fuel filter | Clean the fuel filter if dirty. In that case, check the gas tank, as this is the most likely culprit. | |
Check the gas supply | Check the fuel level and add if needed. Ensure that the gas can flow to the carburetor. Remove any blockage. | |
Check the Air-filter | Clean the air filter. Replace it when it is in bad condition or it is a paper air filter. | |
Check the carburetor | Remove and clean the carburetor with some carb cleaner. It is also possible to clean it without removing it. | |
Fuel gap blocked | Check that the hole in the fuel cap is open. Clean if needed. | |
The engine is stalling, or starts and stops | Check the carburetor | Remove and clean the carburetor with some carb cleaner. It is also possible to clean it without removing it. |
Air filter | Clean the air filter. Replace it when it is in bad condition or it is a paper air filter. | |
Check for bad gas | Suppose you have old gas, more than a few months old. It can turn bad. Drain and replace the gas. Next time add a fuel stabilizer. |
● Titan Powerhorse Electric Pressure Washer Motor troubleshooting table:
Problem | Cause | Solution |
The motor won’t start | The power switch is in the “OFF” or “0” state | Turn the power switch “ON” or “1” |
Cord not plugged | Plugin the power cord | |
Damaged, too long, or improper extension cord | Replace the existing cord with a 25′ (7.6m) 14 AWG cord or a 50′ (15m) 12 AWG cord | |
Inadequate power from the electrical outlet | Plug the cord into a different outlet | |
The pressure washer circuit breaker tripped | Please wait for the washer to cool down and restart it | |
The motor buzzes but fails to run | Loss in voltage due to the extension cord | Plug the unit directly into the outlet without an extension cord. If the problem isn’t solved, replace the extension cord |
Low supply voltage | Ensure that only the pressure washer runs on that circuit at the time of use | |
Residual pressure in the system | Shut off the washer and squeeze the trigger to release pressure | |
Residual friction among the internal components | Cut the water supply and turn the machine ON for 2 to 3 seconds. Try it a couple of times or until the motor starts. Don’t let the machine run dry for more than 3 seconds. | |
Unit not used for long periods | I recommend calling a professional for help | |
Motor not working | Faulty Timer | Disconnect the leads from the timer. If your pressure washer doesn’t turn off after the time out, the timer is faulty, and you need to replace it. |
